4mm 6mm 8mm 10mm Float Glass Production Line Whole Compelelty Solution
1. Brief Description
The name of float glass is because of the glass liquid floating and forming on a metallic tin liquid surface. By using this forming method, it is not need to overcome the gravity of the glass, it can enlarge the width of the glass, improve the speed of stretch, and increase the capacity and scale of production.
JEFFER Engineering and Technology Co., Ltd has already designed and completed equipment supply over different hundreds glass plants in China and abroad.
2. Techncial Advantages
| Item | Description |
| 1 | 3D modeling design |
| 2 | Single/double/multi pass regenerator |
| 3 | Chimney located at the top of regenerator |
| 4 | Unique port structure |
| 5 | Deep refining technology |
| 6 | Unique throat cooling structure |
| 7 | Optimized tank wall cooling arrangement |
| 8 | Underport burner firing technology |
| 9 | Separate regenerator chamber technology |
| 10 | Electrical boosting technology |
| 11 | Bubbling technology |
| 12 | Intelligent single/dual fuel combustion system |
| 13 | Rich oxygen combustion technology |
| 14 | Full oxygen combustion technology |
| 15 | Induced draft fan exhaust technology |
| 16 | Injector fan exhaust technology |
| 17 | Key structure pre-assembly before delivery |
| 18 | Low energy consumption and long life technology |
| 19 | Advanced and reliable computer automatic control system (PLC/DCS, SCADA) |
3. Scope of Supply
| Item | Description |
| 1 | Melting furnace |
| 2 | Tin batch |
| 3 | Annealing lehr |
| 4 | Cold-end equipment |
| 5 | Cullet return system |
| 6 | Shielding gas mixing station |
4. Raw Materials
Main materials are mainly including:
| Silica Sand |
| Dolomite |
| Limestone |
| Feldspar |
| Soda Ash |
| Salt Cake |
| Cullet |
Auxiliary materials as the important raw materials, it mainly includes:
| Clarify Agent |
| Coloring Agent |
| Decolorizing Agent |
| Oxidizing Agent |
| Reducing Agent |
| Combustion Agent |
5. Technical Flow Chart of Float Glass Line
6. Main Equipment Description
6.1 Batch Plant
For batching and mixing the raw materials.
6.2 Furance
The melting tank is key part of glass production line, the refractory materials quality is very important.
6.3 Tin Bath
Glass liquid float on the metallic tin, through stretching, forming, polishing and cooling processing, a qualified glass plate is formed and its temperature reduces around 600°C, the transition roller will send the plate to annealing lehr.
6.4.Protection Gas Station
The protection gas station shall operate continuously to produce and supply the required gas for tin bath.
Tin is easy to reaction with oxygen, sulfur under high temperature and form an oxide, its oxide (SnO2, SnO) will seriously pollute the glass liquid, this will affect the quality of the glass.
6.5. Annealing Lehr
In glass technology, annealing means to put the glass into the annealing lehr for a certain time or reduce the temperature with a slow speed, so as to no additional permanent stress or temporary stress will produce. Namely, annealing also means a process which will reduce or eliminate the thermal stress of glass.
6.6. Colde-end
It mainly divides into three sections for cold-end part in float glass production line. Details are following:
- Inspection and pretreatment section
- Cutting and break section
- Stacker and packing section
7. FAQ
Q: Who we are?
A: JEFFER Engineering and Technology Co., Ltd is a professional engineering company specialising in project design, engineering technology consulting, engineering, procurement, construction (EPC), and project operation management.
Q:Can you offer design service?
A: Yes, we could design full solution drawings as per your requirements.
Q: How can I get the price
A: For product line, please provide the detailed specfication of the production you want to product, then we will privode an economic plan for your reference. For engineering service, please provide your requirement, we will provide the detailed schedule and plan for your reference.
Q: Which shipment is available?
A: By sea, by air, by rail or as your requirement.
